- Country
- Japan
- Manufacturer / Brand
- Icom, Inoue Communication Equipment Corp.; Osaka
- Year
- 2000
- Category
- Amateur TRX: Transmitter/Receiver (and Transceiver)
- Radiomuseum.org ID
- 177087
-
- alternative name: INOUE COMM. E. CORP
FA 2/01
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet, double/triple conversion; ZF/IF 64455/455 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Powered by external power supply or a main unit. / DC 13,8 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 2 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: IC-718 - Icom, Inoue Communication
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 240 x 95 x 239 mm / 9.4 x 3.7 x 9.4 inch
- Notes
- Icom KW-Transceiver IC-718.
Frequenzbereich TX: alle Amateurfunkbänder von 160 bis 10 m, RX: 0,03-30 MHz; Betriebsarten: SSB, AM, CW, RTTY; Pout: 5...100 W (AM 5...40 W).
Zwei VFOs; ZF-Shift; RIT; Sprachkompressor; VOX; elektronischer Keyer für CW; 101 Speicher; DSP-Einheit UT-106 optional; Stromaufnahme Senden: 20 A, Empfang 2 A.
- Net weight (2.2 lb = 1 kg)
- 3.8 kg / 8 lb 5.9 oz (8.37 lb)
- Price in first year of sale
- 2,045.00 DM
- Mentioned in
- FA 2/01
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
