• Country
• Austria

• Manufacturer / Brand
• ITT Schaub-Lorenz Wien

• Year
• 1981 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 124268

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 10

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 468 kHz; 1 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast, Long Wave and FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 220-240 / AA: 4 x 1,5 Volt

• Loudspeaker
• -Loudspeaker incorporated, but system not known.

• Power out
• 0.4 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Tiny 200 - ITT Schaub-Lorenz Wien

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 217 x 145 x 58 mm / 8.5 x 5.7 x 2.3 inch

• Net weight (2.2 lb = 1 kg)
• 0.8 kg / 1 lb 12.2 oz (1.762 lb)

• Literature/Schematics (1)
• -- Schematic

• Author
• Model page created by Johannes Bernhauser. See "Data change" for further contributors.
