S.E.A. Graphic Equalizer KS-E7
JVC - Victor Company of Japan, Ltd.; Tokyo
- Country
- Japan
- Manufacturer / Brand
- JVC - Victor Company of Japan, Ltd.; Tokyo
- Year
- 1983
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 254953
Aus den Hersteller-Unterlagen
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 5
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 14,4 Volt
- Loudspeaker
- - For headphones or amp.
- Material
- Metal case
- from Radiomuseum.org
- Model: S.E.A. Graphic Equalizer KS-E7 - JVC - Victor Company of Japan,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 150 x 30 x 150 mm / 5.9 x 1.2 x 5.9 inch
- Notes
-
Equalizer für den Kfz-Bereich; wird zwischen Autoradio und Leistungsendstufen geschaltet. Zum Anbau z.B. unter dem Amaturenbrett. 7 Flachbahn-Potentiometer zur Einstellung des gewünschten Klangbildes.
- Net weight (2.2 lb = 1 kg)
- 0.7 kg / 1 lb 8.7 oz (1.542 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
