• Year
  • 1927 ?
  • Category
  • Detector-Radio (Crystal or diode, without tubes/transistors)
  • Radiomuseum.org ID
  • 77900

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Crystal or Solid State Detector
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • No Power needed
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Detektor-Empfänger RDC5 - Kramolin; München und Berlin
  • Shape
  • Tablemodel without push buttons, Mantel/Midget/Compact up to 14
  • Dimensions (WHD)
  • 125 x 30 x 175 mm / 4.9 x 1.2 x 6.9 inch
  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Author
  • Model page created by Henryk Berezowski. See "Data change" for further contributors.
