Kolibri ; Kuba Imperial; (ID = 20391) Radio
Kuba Imperial;: Kolibri [Radio] ID = 20391 605x409
Select picture or schematic to display from thumbnails on the right and click for download.
For model Kolibri, Kuba (Imperial); Wolfenbüttel

Country:  Germany
Manufacturer / Brand:  Kuba (Imperial); Wolfenbüttel
alternative name

Imperial Kuba
Year: 1960–1963 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECC85 ECH81 EF89 EABC80 EL95
Main principle Super-Heterodyne (Super in general); ZF/IF 472/10700 kHz
Tuned circuits 6 AM circuit(s)     9 FM circuit(s)
Wave bands Broadcast, Long Wave and FM or UHF.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 3 W (unknown quality)
from Radiomuseum.org Model: Kolibri - Kuba Imperial; Wolfenbüttel
Material Bakelite case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 320 x 215 x 175 mm / 12.6 x 8.5 x 6.9 inch
Notes in verschiedenen modischen Farben. Gehäuse in hellgrau, taubenblau oder weinrot mit elfenbeinfarbigem Frontteil.
Net weight (2.2 lb = 1 kg) 3.5 kg / 7 lb 11.3 oz (7.709 lb)
Price in first year of sale 180.00 DM
Collectors' prices
External source of data E. Erb 3-907007-36-0
Source of data HdB d.Rdf-& Ferns-GrH 1960/61 / Radiokatalog Band 2, Ernst Erb
Picture reference Das Modell ist im «Radiokatalog» (Erb) abgebildet.


All listed radios etc. from Kuba (Imperial); Wolfenbüttel
Here you find 720 models, 668 with images and 156 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
