Curve Tracer LTC-905

• Country
• Japan

• Manufacturer / Brand
• Leader Electronics Corp.; Yokohama

• Year
• 1976 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 127855

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors
• 2SC458 2SC458

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 100; 115; 200; 215; 230 Volt

• Loudspeaker
• - - No sound reproduction output.

• from Radiomuseum.org
• Model: Curve Tracer LTC-905 - Leader Electronics Corp.;

• Shape
• Tablemodel, with any shape - general.

• Notes
• ICs: 3
  Kennlinienschreiber; Vorsatzgerät zum Oszilloskop.
  Prüfmöglichkeit: NPN-, PNP-, FET-, und MOS-FET-Transistoren; Thyristoren und Triacs; Dioden, Zener- und Tunneldioden, Gleichrichter.
  Ausgang H/V zum Oszilloskop.
