Grid Dip Meter LDM-810

Grid Dip Meter LDM-810; Leader Electronics (ID = 117725) Equipment
Use red slider bar for more.
Grid Dip Meter LDM-810; Leader Electronics (ID = 117725) Equipment
Leader Electronics: Grid Dip Meter LDM-810 [Equipment] ID = 117725 640x419
Select picture or schematic to display from thumbnails on the right and click for download.
For model Grid Dip Meter LDM-810, Leader Electronics Corp.; Yokohama

Country:  Japan
Manufacturer / Brand:  Leader Electronics Corp.; Yokohama
Year: 1965 ?? Type: Service- or Lab Equipment
Valves / Tubes 1: 6CW4
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Alternating Current supply (AC) / 115/230 Volt
Loudspeaker - only for Earphone!
Power out
from Radiomuseum.org Model: Grid Dip Meter LDM-810 - Leader Electronics Corp.;
Material Metal case
Dimensions (WHD) 70 x 50 x 170 mm / 2.8 x 2 x 6.7 inch
Notes Nuvistor dipmeter, 2.0 - 250 MHz in six ranges.
Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Mentioned in -- Original-techn. papers.

Model page created by a member from D. See "Data change" for further contributors.



All listed radios etc. from Leader Electronics Corp.; Yokohama
Here you find 109 models, 107 with images and 53 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.


Collection of a member from D




Forum contributions about this model
Leader Electronics: Grid Dip Meter LDM-810
Threads: 1 | Posts: 1
Hits: 750     Replies: 0
leader2: LDM-810; Grid Dip Meter
Robert Forbes
09.Sep.12
  1

Re the manufacture date, I bought mine new in Tokyo in 1964.
