PKV-6 {ПКВ-6}

Leningrad Kozitsky Works

  • Year
  • 1928
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 163273
    • alternative name: Radiotelegraf Works

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF with regeneration
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Storage and/or dry batteries / 4; 80 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: PKV-6 {ПКВ-6} - Leningrad Kozitsky Works
  • Shape
  • Tablemodel, with any shape - general.
  • Notes
  • Coverage 12-300 m band in six ranges, changed six different external coils in schemat. Vertical or dipole antenna usable.
  • Mentioned in
  • -- Schematic (R. Malinin "Radio sets" 1937, Moscow)
  • Author
  • Model page created by Zenonas Langaitis. See "Data change" for further contributors.
