Raduga {Радуга} 5BG {5БГ}
Leningrad Kozitsky Works
- Country
- Soviet Union
- Manufacturer / Brand
- Leningrad Kozitsky Works
- Year
- 1969 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 128409
-
- alternative name: Radiotelegraf Works
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 13
- Valves / Tubes
- 59ЛК3Ц
- Number of Transistors
- 49
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 38900 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
- Power out
- 3 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Raduga {Радуга} 5BG {5БГ} - Leningrad Kozitsky Works
- Shape
- Tablemodel, with any shape - general.
- Notes
- Secam- Farbfernsehgerät nach CCIR, VHF Band I und Band III, UHF von Kanal 21 bis Kanal 40 mit einem Tunerbaustein aus Stassfurt. AFC für alle Bereiche. Netzgetrenntes Gerät, großes Vertikalchassis. 1969 in der DDR verkauft.
- Net weight (2.2 lb = 1 kg)
- 65 kg / 143 lb 2.7 oz (143.172 lb)
- Price in first year of sale
- 3,100.00 DM
- Mentioned in
- Zeitschrift Radio Fernsehen Elektronik Jahrgang 1970 Heft 19 Seite 523
- Literature/Schematics (1)
- Importgeräte- CD vom Funkverlag B. Hein
- Author
- Model page created by Wolfgang MICHAEL. See "Data change" for further contributors.
