Gouverneur ; Loewe Bruxelles - (ID = 1256906) Radio
Loewe Bruxelles -: Gouverneur [Radio] ID = 1256906 600x450
Select picture or schematic to display from thumbnails on the right and click for download.
For model Gouverneur, Loewe Bruxelles - voir Loewe Germany

Country:  Belgium
Manufacturer / Brand:  Loewe Bruxelles - voir Loewe Germany
Year: 1938 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6A7 6D6 6B7 42 80
Main principle Super-Heterodyne (Super in general)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 130; 140; 220; 240 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 25 cm = 9.8 inch
Power out
from Radiomuseum.org Model: Gouverneur - Loewe Bruxelles - voir Loewe
Material Wooden case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 540 x 345 x 290 mm / 21.3 x 13.6 x 11.4 inch
Notes Das Gerät hat eine Schattenabstimmanzeige für die Sendereinstellung.
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Collectors' prices

Model page created by Hartmut Daniels † 22.11.16. See "Data change" for further contributors.



All listed radios etc. from Loewe Bruxelles - voir Loewe Germany
Here you find 1 models, 1 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
