Apollo 4760W

Apollo 4760W; Loewe-Opta; (ID = 44756) Radio
Apollo 4760W; Loewe-Opta; (ID = 36322) Radio Apollo 4760W; Loewe-Opta; (ID = 36323) Radio
Apollo 4760W; Loewe-Opta; (ID = 36324) Radio Apollo 4760W; Loewe-Opta; (ID = 684806) Radio
Apollo 4760W; Loewe-Opta; (ID = 772493) Radio Apollo 4760W; Loewe-Opta; (ID = 1188147) Radio
Apollo 4760W; Loewe-Opta; (ID = 1188152) Radio Apollo 4760W; Loewe-Opta; (ID = 1188153) Radio
Apollo 4760W; Loewe-Opta; (ID = 1188154) Radio Apollo 4760W; Loewe-Opta; (ID = 1188155) Radio
Use red slider bar for more.
Apollo 4760W; Loewe-Opta; (ID = 36322) Radio
Loewe-Opta;: Apollo 4760W [Radio] ID = 36322 933x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Apollo 4760W, Loewe-(Opta); Deutschland

Country:  Germany
Manufacturer / Brand:  Loewe-(Opta); Deutschland
alternative name

Löwe Radio
Year: 1959/1960 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM84 EL84
Principle Super-Heterodyne (Super in general); ZF/IF 460 kHz
Tuned circuits 6 AM circuit(s)     12 FM circuit(s)
Wave bands Broadcast, (BC) Long Wave (LW), 2 x SW and FM.
Details
Power type and voltage Alternating Current supply (AC) / 110; 127; 160; 220 Volt
Loudspeaker 3 Loudspeakers
Power out
from Radiomuseum.org Model: Apollo 4760W - Loewe-Opta; Deutschland
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 580 x 360 x 250 mm / 22.8 x 14.2 x 9.8 inch
Notes Diode: OA200. Bandbreite schaltbar.
Net weight (2.2 lb = 1 kg) 10.5 kg / 23 lb 2 oz (23.128 lb)
Price in first year of sale 369.00 DM
Collectors' prices
External source of data Erb
Source of data HdB d.Rdf-& Ferns-GrH 1959/60
