• Country
• Sweden

• Manufacturer / Brand
• Luxor Radio AB; Motala

• Year
• 1959 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 191563

• • alternative name: Luxorita - voir Luxor Radio AB Suède (Sweden)

• Number of Transistors
• 6

• Semiconductors
• OC44 OC45 OC45 OC75 OC74 OC74 OA79

• Main principle
• Superheterodyne (common); 2 AF stage(s)

• Tuned circuits
• 5 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Dry Batteries / 6 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: BT-365 - Luxor Radio AB; Motala

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 210 x 155 x 65 mm / 8.3 x 6.1 x 2.6 inch

• Notes
• Anschluss für Zusatzlautsprecher.

• Source of data
• - - Data from my own collection

• Author
• Model page created by Manfred Kröll † 2.9.2013. See "Data change" for further contributors.
