R.A.C.I.
Magnadyne Radio; Torino
- Country
- Italy
- Manufacturer / Brand
- Magnadyne Radio; Torino
- Year
- 1938/1939
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 30609
Pubblicità d\'epoca
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 4
- Main principle
- Superheterodyne (common); ZF/IF 362 kHz; Reflex
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage and/or dry batteries / 12 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Material
- Metal case
- from Radiomuseum.org
- Model: R.A.C.I. - Magnadyne Radio; Torino
- Notes
- Alimentazione con dinamotore per l'anodica. Dimensioni di 27,5 x 17 x 18 cm (base); 16 x 8,5 x 13 cm (sintonizzatore). Autoradio vincitrice del concorso indetto dal Regio Automobil Club d'Italia (RACI) nel 1937. Modello presentato a fine 1937, ma con inizio commercializzazione primavera 1938.
- Net weight (2.2 lb = 1 kg)
- 10 kg / 22 lb 0.4 oz (22.026 lb)
- Price in first year of sale
- 1,600.00 ITL
- Source of data
- Guida Pratica Antique Radio II (2000)
- Literature/Schematics (1)
- Il Radio Libro (E.D. Ravalico) Edizioni Hoepli
- Literature/Schematics (2)
- Radiocorriere, n. 37, 1937
- Literature/Schematics (3)
- -- Schematic (La Riparazione degli Apparecchi Radio, Delforno - Colciago, Italy 1941)
- Author
- Model page created by Alessandro De Poi. See "Data change" for further contributors.
