• Year
  • 1956 ?
  • Category
  • Television Receiver (TV) or Monitor
  • Radiomuseum.org ID
  • 268135

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Superhet with RF-stage
  • Wave bands
  • VHF incl. FM and/or UHF (see notes for details)
  • Power type and voltage
  • Alternating Current supply (AC) / 60 cycles, 105-120 Volt
  • from Radiomuseum.org
  • Model: Ch= CTA435AA 250Series - Magnavox Co., Commercial
  • Author
  • Model page created by Dirk Taekels. See "Data change" for further contributors.
