6 Serie 1935
Magnétic, Société G.S.L.; Liège
- Country
- Belgium
- Manufacturer / Brand
- Magnétic, Société G.S.L.; Liège
- Year
- 1935 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 88519
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); Reflex
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- Alternating Current supply (AC) / 110; 130; 140; 220; 245 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
- Power out
- 5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 6 [Serie 1935] - Magnétic, Société G.S.L.;
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 410 x 430 x 280 mm / 16.1 x 16.9 x 11 inch
- Price in first year of sale
- 2,250.00 Bfr
- Mentioned in
- Belgische Radioconstructeurs in het Interbellum by Guido Nys, p, 233
- Author
- Model page created by Albert Aerts †. See "Data change" for further contributors.
- Other Models
-
Here you find 11 models, 10 with images and 2 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Magnétic, Société G.S.L.; Liège
