For model FM/AM Signal Generator TF 995A/2M, Marconi Instruments Ltd., St. Albans

Country:  Great Britain (UK)
Manufacturer / Brand:  Marconi Instruments Ltd., St. Albans
Year: 1965 ?? Category: Service- or Lab Equipment
Valves / Tubes 13: 6AK5 6AK5 6AK5 6AK5 6AK5 6AK5 6AK6 6AK6 6AL5 6AL5 6AU6 12AT7 5Z4G 0A2 5651
schematic requested
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 100; 105; 120; 140; 200; 205; 220; 240 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: FM/AM Signal Generator TF 995A/2M - Marconi Instruments Ltd., St.
Material Metal case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 440 x 320 x 220 mm / 17.3 x 12.6 x 8.7 inch
Notes 1,5 to 220 MHz in 5 ranges, CW, AM and FM.
Modulation intern and extern.
Net weight (2.2 lb = 1 kg) 16.4 kg / 36 lb 2 oz (36.123 lb)
Collectors' prices
Source of data - - Manufacturers Literature

Model page created by Bernardo Diaz. See "Data change" for further contributors.
