ERMSA Generador de señales C 5-3 (S-3)

Maymo, Escuela Radio; Barcelona etc.

Data
Forum
Pictures
Collections

  • Year
  • 1953
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 151688
    • alternative name: ERMSA

 Technical Specifications

  • Number of Tubes
  • 2
  • Main principle
  • RF-Circuit or wave trap (separate, can also be an antenna with amp.)
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 125 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: ERMSA Generador de señales C 5-3 - Maymo, Escuela Radio;
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 250 x 190 x 115 mm / 9.8 x 7.5 x 4.5 inch
  • Notes

  • ERMSA Generador de señales tipo C 5-3

    100 kHz - 18 MHz en 5 bandas. Salida RF y RF modulada a 500 c/s.

  • Net weight (2.2 lb = 1 kg)
  • 1.5 kg / 3 lb 4.9 oz (3.304 lb)
  • Literature/Schematics (1)
  • Revista Noticiario Maymó nr. 7 1953
  • Author
  • Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
