• Year
  • 1983
  • Category
  • Commercial Receiver (may include amateur bands)
  • Radiomuseum.org ID
  • 137583

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Short Wave (SW only)
  • Power type and voltage
  • Line / Batteries (any type) / 220 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: REV 251 T - Mechanikai Laboratórium ML;
  • Shape
  • Boatanchor (heavy military or commercial set >20 kg).
  • Dimensions (WHD)
  • 444 x 392 x 310 mm / 17.5 x 15.4 x 12.2 inch
  • Notes
  • 200 kHz- 30 MHz.

  • Net weight (2.2 lb = 1 kg)
  • 31 kg / 68 lb 4.5 oz (68.282 lb)
  • Source of data
  • -- Collector info (Sammler)
  • Literature/Schematics (1)
  • Dékány-Szönyi: A magyar katonai rádiófelderítés története.
  • Literature/Schematics (2)
  • -- Original-techn. papers.
