05WG-2747B (05 WG2747 B)

Image ID = 249914 for Montgomery Ward & Co 05WG-2747B

Image ID = 249915 for Montgomery Ward & Co 05WG-2747B

Image ID = 249916 for Montgomery Ward & Co 05WG-2747B

Image ID = 249917 for Montgomery Ward & Co 05WG-2747B
Image ID = 249914 for Montgomery Ward & Co 05WG-2747B

Country: United States of America (USA) Manufacturer/Brand: Montgomery Ward & Co.; Chicago (IL)
Year: 1953 ?? Type: Radio or Tuner
Valves / Tubes 8: 6BE6 12AT7 6BA6 6BA6 6AL5 6AV6 6V6GT 6X5GT
Principle Super-Heterodyne (Super in general); IF-Freq. 455/10700 kHz
Wave bands Broadcast (BC) and FM.
Details Record Player (perh.Changer)
Power type and voltage Alternating Current supply (AC) / 105 - 125 Volt
Loudspeaker/pwr.out Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / 0.8 W / Ø 20.3 cm = 8 inch
from Radiomuseum.org Model: 05WG-2747B

All listed radios etc. from Montgomery Ward & Co.; Chicago (IL)
Here you find 1444 models, 489 with images and 1346 with schematics.
