Airline 93WG-2208A Order= 451 B 2208 Portable Radio Phonograph

Montgomery Ward & Co. (Wards, Airline); Chicago, IL

Data
Forum
Pictures
Collections

  • Year
  • 1939–1941
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 48511
    • Brand: Airline or Air-Line

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 456 kHz; 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast only (MW).
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Dry Batteries / 1.5 & 2 x 45 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
  • Power out
  • 0.15 W (0.35 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Airline 93WG-2208A Order= 451 B 2208 Portable Radio Phonograph - Montgomery Ward & Co. Wards,
  • Shape
  • Tablemodel, Box - most often with Lid (NOT slant panel).
  • Dimensions (WHD)
  • 15.25 x 9 x 13.75 inch / 387 x 229 x 349 mm
  • Notes

  • The Airline 93WG-2208A is a combination battery operated 5 tube BC band receiver and spring loaded record player.  The BC band frequency tuning range is 540 to 1600kHz. Has built-in loop antenna with provisions for connecting an external antenna. Uses Qty(1) 1.5V "A" battery and Qty(2) 45V "B" batteries.

    The same schematic for this model is also used for the following models:

    Model Type
    Airline 93WG-565A Radio
    Airline 93WG-2208A Radio/Phonograph
    Airline 93WG-2565A Radio

    This model was built for Montgomery Ward by the Wells Gardner Co, Chicago, ILL.

    NOTE: Starting in 1939, Montgomery Ward began adding the production series in the model number, with the letter "A" in the model number indicating the first production series.  Other service documentation (such as Riders) did not consistantly use the "A" in the model number when referring to the first production series models. However models without the "A" at the end of the model number are the same as the models with the "A".

  • Price in first year of sale
  • 34.50 $
  • External source of data
  • Ernst Erb
