49-B (49 B) Ch= A04 (A 04)

ID = 48810

Country: United States of America (USA)	Manufacturer/Brand: Motorola Inc.; Schaumburg (IL)
Year: 1947 ??	Type: Car Radio
Valves / Tubes	7: 6SK7GT 6SH7GT 6SK7GT 6R7GT 6V6GT 6V6GT 0Z4

Principle	not available; IF-Freq. 262 kHz
Tuned circuits	8 AM circuit(s);
Wave bands	Broadcast only (MW).
Power type and voltage	Storage Battery for all / 6 Volt
Loudspeaker/pwr.out	Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
from Radiomuseum.org	Model: 49-B Ch= A04
Notes	Vibrator for +B

All listed radios etc. from Motorola Inc.; Schaumburg (IL)
Here you find 2128 models, 716 with images and 2006 with schematics.
