53C1B Ch= HS-400

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077129) Radio

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077130) Radio

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077131) Radio

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077132) Radio

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077133) Radio

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077134) Radio

53C1B Ch= HS-400; Motorola Inc.; (ID = 1077135) Radio
53C1B Ch= HS-400; Motorola Inc.; (ID = 1083070) Radio
Use red slider bar for more.
53C1B Ch= HS-400; Motorola Inc.; (ID = 1083070) Radio
Motorola Inc.;: 53C1B Ch= HS-400 [Radio] ID = 1083070 933x594
Select picture or schematic to display from thumbnails on the right and click for download.
For model 53C1B Ch= HS-400, Motorola Inc.; Schaumburg (IL):
Picture from Motorola datasheet

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc.; Schaumburg (IL)
alternative name

Galvin Mfg. Co. ; Chicago
Year: 1960 ?? Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BD6 12AT6 50C5 35W4
Principle Super-Heterodyne (Super in general); ZF/IF 455 kHz
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 117 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: 53C1B Ch= HS-400 - Motorola Inc.; Schaumburg IL
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, with any shape - general.
Notes

Clock Radio
Color = Walnut

Source of data - - Manufacturers Literature

Model page created by John Kusching. See "Data change" for further contributors.
