Model: 62X11U (62 X 11 U) Ch= HS-314 (HS314)
Antique radios, Old Time Radios
62X11U (62 X 11 U) Ch= HS-314 (HS314)
Country:
United States of America (USA)
Manufacturer/Brand:
Motorola Inc.; Schaumburg (IL)
Year: 1952
Type:
Radio or TunerBroadcast receiver (Radio).
Im Gegensatz zu Radioempfängern für kommerzielle und/oder militärische Zwecke und den frühen Empfängern für Morsezwecke nennen wir hier Radio bzw. Rundfunkempfänger. Aber: Gemäss internationaler Sprachregelung führt der Radiokatalog Band 1 alle Empfänger mit aktiven Bauteilen als RADIO. Wir unterscheiden hier ebenfalls nicht, ob mit Röhren bestückt, hybrid, mit Transistoren oder/und ICs.
Mod.-ID = 49115
