SH22GL Ch= HS-831 HS-832

SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 1156978) R-Player

SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 1156979) R-Player

SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 1156980) R-Player

SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 1156981) R-Player

SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 146189) R-Player
SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 1156977) R-Player
Use red slider bar for more.
SH22GL Ch= HS-831 HS-832; Motorola Inc.; (ID = 1156977) R-Player
Motorola Inc.;: SH22GL Ch= HS-831 HS-832 [R-Player] ID = 1156977 933x733
Select picture or schematic to display from thumbnails on the right and click for download.
For model SH22GL Ch= HS-831 HS-832, Motorola Inc.; Schaumburg (IL):
Picture from Motorola datasheet

Country:  United States of America (USA)
Manufacturer / Brand:  Motorola Inc.; Schaumburg (IL)
alternative name

Galvin Mfg. Co. ; Chicago
Year: 1960 Type: Recorder and/or Player
Valves / Tubes 6: 12AX7 6BM8 6BM8 6BM8 6BM8 6CA4
Principle Audio-Amplification
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 120 Volt
Loudspeaker 5 Loudspeakers
Power out 14 W (unknown quality)
from Radiomuseum.org Model: SH22GL Ch= HS-831 HS-832 - Motorola Inc.; Schaumburg IL
Material Leather / canvas / plastic - over other material
Shape Tablemodel, with any shape - general.
Notes The Motorola Model SH22GL is an AC operated 6 Tube, three channel portable stereo Phono Amplifier and 4 Speed Automatic Record Changer. Uses audio-amp chassis HS-831 and power supply chassis HS-832. Cabinet color is Gold. This model has Qty(1) 8" PM speaker, Qty(2) 5.25" PM speakers and Qty(2) 4" PM speakers. Uses Record Changer VM43RC. Has separate bass channel that drives the 8" speaker.
Circuit diagram reference Beitman Radio Diagrams Vol. 21, 1961
Literature/Schematics (1) - - Manufacturers Literature

Model page created by Egon Penker. See "Data change" for further contributors.
