Brillant Art. Nr. 821/20 Ch= 20130

Neckermann-Versand KG; Frankfurt a.M.

Data
Forum
Pictures
Collections

  • Year
  • 1958/1959 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 26817
    • Brand: Twen Tone

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 7
  • Main principle
  • Superheterodyne (common); ZF/IF 472/10700 kHz
  • Wave bands
  • Broadcast, Long Wave and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 110-240 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Brillant Art. Nr. 821/20 Ch= 20130 - Neckermann-Versand KG;
  • Shape
  • Tablemodel with Push Buttons.
  • Dimensions (WHD)
  • 503 x 315 x 212 mm / 19.8 x 12.4 x 8.3 inch
  • Notes

  • Modell 821/20 mit dreifach Klangregister, zwei Skalenlampen und zwei seitlichen elektrostatischen Lautsprechern. Schaltbild ist vom 821/12 (ohne Klangregister, ohne elektrostatische Lautsprecher, sonst jedoch identisch).

    Hergestellt von Körting.

  • Source of data
  • Radiokatalog Band 2, Ernst Erb
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Brillant is part of the collections of the following members.

 Forum

Forum contributions about this model: Neckermann-Versand: Brillant Art. Nr. 821/20 Ch= 20130

Threads: 2 | Posts: 8

Hello Dear Radio Friends,

 I have a question concerning the volume potentiometer on this radio.  Mine is broken, and upon disassembly and inspection I found that the small phenolic disk inside was broken in half.  My first thought was to replace the potentiometer with a similar 1,3M Ohm pot and cut the pole to the required length.  The original pot diameter seems quite small compared to other radios of similar design.  And the one I have selected as a replacement is rather a tight fit.  So I am attempting to repair the original phenolic disk and reassemble to original pot.  I fixed the two halves with Super-Glue, but I know that this is only a temporary solution and won't last very long.  So my question is: how would you proceed?  Would you glue the halves together using some epoxy compound or other bonding agent?  Or would you attempt to somehow make a replacement phenolic disk?  I appreciate your thoughts and consideration.

Kind Regards,

Bob Isaac

Bob Isaac, 02.Mar.12

Weitere Posts (4) zu diesem Thema.

Hallo, Zusammen,

beim Neckermann Brillant 821 gibt es offensichtlich verschiedene Varianten. Der mir vorliegende Schaltplan für 821/12 ( 20130 ) ( eine Skalenlampe, kein Klangregister, keine elektrostatischen Lautsprecher seitlich )  passt nicht ganz zur zugehörigen Abgleichanleitung ( 21330 ), wo 2 Skalenlampen und das Klangregister explizit erwähnt werden. Die Röhrenbestückung und weitere Daten scheinen identisch. Mein Gerät entspricht dem abgebildeten 821/20.

Weiss vielleicht jemand etwas näheres?

Danke!!

H.Oelkers

Henning Oelkers, 09.Feb.04

Weitere Posts (4) zu diesem Thema.
