Imperator Ch= StL 11/23 - Rfk = 1/632
Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Country
- Germany
- Manufacturer / Brand
- Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen
- Year
- 1960/1961
- Category
- Television- and Radio Receiver, perh. also + Rec. etc. (TV Radio)
- Radiomuseum.org ID
- 270198
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 27
- Valves / Tubes
- PCC88 PCF82 EF183 EF80 PM84 EF80 PCL84 PCF80 PCF80 EF80 PCL86 ECL80 PCL82 ECH81 PL36 PY88 DY86 AW59-90 ECC85 ECH81 EF85 EABC80 EM84 ECC83 ECC83 EL84 EL84
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- Changer (Record changer)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- 4 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Imperator Ch= StL 11/23 - Rfk = 1/632 - Nordmende, Norddeutsche Mende-
- Shape
- Console with any shape - in general
- Notes
-
Fernsehchassis = Konsul 61 Ch= StL11 aber 59cm Bildröhre AW59-90.
Radiochassis = Othello Stereo Ch= 1/632
- Mentioned in
- HdB d.Rdf-& Ferns-GrH 1960/61
- Literature/Schematics (1)
- -- Original-techn. papers.
- Author
- Model page created by Wolfgang Bauer. See "Data change" for further contributors.
