Parsifal-Stereo E17 Ch= 1/616

• Country
• Germany

• Manufacturer / Brand
• Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

• Year
• 1960/1961

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 23434

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 8

• Valves / Tubes
• ECC85 ECH81 EF89 EABC80 EM84 EBC81 EL84 EL84

• Number of Transistors

• Semiconductors
• 464.010.15

• Main principle
• Superheterodyne (common); ZF/IF 460/10700 kHz

• Tuned circuits
• 6 AM circuit(s)     10 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Alternating Current supply (AC) / 110; 125; 150; 220; 240 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Parsifal-Stereo E17 Ch= 1/616 - Nordmende, Norddeutsche Mende-

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 575 x 340 x 255 mm / 22.6 x 13.4 x 10 inch

• Notes

• Stereo-NF-Verstärker mit 2 Endstufen je 3 W.
  Siehe auch die Export-Version Nordmende Sterling USA Parsifal-us Ch= 1/616US.
  See also the US version Nordmende Sterling, USA.Parsifal-us Ch= 1/616US.

• Net weight (2.2 lb = 1 kg)
• 10.8 kg / 23 lb 12.6 oz (23.789 lb)

• Price in first year of sale
• 316.00 DM

• External source of data
• Erb

• Source of data
• HdB d.Rdf-& Ferns-GrH 1960/61

• Mentioned in
• Funk-Technik (FT) (14/1960, S. 508, 509 / Beschreibung, Schema HF u. ZF)

• Literature/Schematics (1)
• -- Original-techn. papers.
