Transita TS de Luxe V02 Ch= 5/602 Skala mit 1 Schraube befestigt

Nordmende, Norddeutsche Mende-Rundfunk GmbH (Sterling), Bremen-Hemelingen

Data
Forum
Pictures
Collections

  • Year
  • 1965/1966
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 7676

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 11
  • Main principle
  • Superheterodyne (common); ZF/IF 460/10700 kHz
  • Tuned circuits
  • 7 AM circuit(s)     13 FM circuit(s)
  • Wave bands
  • Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
  • Power type and voltage
  • Dry Batteries / 5 × 1,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
  • Power out
  • 2 W (unknown quality)
  • Material
  • Leather / canvas / plastic - over other material
  • from Radiomuseum.org
  • Model: Transita TS de Luxe V02 Ch= 5/602 [Skala mit 1 Schraube befestigt] - Nordmende, Norddeutsche Mende-
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 295 x 190 x 94 mm / 11.6 x 7.5 x 3.7 inch
  • Notes

  • UKW: 87 - 104 MHz
    LW: 145 - 260 kHz
    MW: 515 -1650 kHz
    KW1: 5950 -6200 kHz
    KW2: 7000 - 18000 kHz

    Betrieb im Auto über Autohalterung aus 6-V- oder 12-V-Autobatterie möglich. Netzbetrieb mit zusätzlichem Netzteil möglich.
    Knobs for on-off/volume and tone; pressing the knobs get light and bass respectively. Tuning indicator, which at the touch of a button reads the battery charge. For phone, press the FM and S keys together. Button FM-AFC/AM-filter key. Jacks for earphone, external antenna, and power 7,5 V; DIN for recorder. On the bottom, antennas trimmer and socket for car power.

    4 Farben: bordeauxrot, deltagrün, kaviar oder tabak.

  • Net weight (2.2 lb = 1 kg)
  • 3.1 kg / 6 lb 13.3 oz (6.828 lb)
  • Mentioned in
  • Funkschau (5/1966, S. 145, 146, 147, 148)
  • Literature/Schematics (1)
  • -- Original-techn. papers.

 Collections | Museums | Literature

Collections

The model Transita TS de Luxe is part of the collections of the following members.

 Forum

Forum contributions about this model: Nordmende,: Transita TS de Luxe V02 Ch= 5/602

Threads: 1 | Posts: 2

Good evening.

Radiomuseum currently does not publish any pictures of the interior of models Nordmende TS de luxe. Having no special technical knowledge, I do not see significant elements to distinguish the three models offered on the site. My device has a label with code 865.602.00. Corresponds it to the model shown as transit TS de Luxe 5 / 602?


If it so is, my model has one screw on the glass, at the center, behind the keys, while on the page dedicated to the 5 / 602 there is a similar picture (the second) and two photos (the third and fourth) that refer to a model with "at least" two screws. I say at least, because the model 1966/67 has three screws (photo 2) and this probably can be seen also from the photo of the model of 1967/68.



What should I do?






Radiomuseum non pubblica attualmente alcuna foto d'interni del modello Nordmende TS de luxe. Non essendo un tecnico, non vedo elementi significativi per distinguere i tre modelli proposti sul sito. Il mio apparecchio porta una targhetta con il codice 865.602.00. Corrisponde al modello indicato come Transita TS de Luxe 5/602?

Se così fosse, il mio modello ha sul vetro una sola vite, al centro, dietro i tasti, mentre sulla pagina dedicata al 5/602 c'è sia una foto in tal senso ( la seconda) che due foto ( la terza e la quarta) che si riferiscono ad un modello con almeno due viti laterali. Dico almeno, perchè il modello del 1966/67 ne possiede tre ( foto n. 2) e questo si desume probabilmente anche dalla foto del modello del 1967/68.

Che cosa devo fare?

Felice Nicolini, 19.Oct.10

Weitere Posts (2) zu diesem Thema.
