• Country
• Canada

• Manufacturer / Brand
• Northern Electric Co. Ltd.; Montreal, QC ; Belleville, ON

• Year
• 1946/1947

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 153472

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 12SA7 12SK7 12SQ7 35L6 35Z5

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• AC/DC-set / 110 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm

• Power out
• 2.5 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: Baby Champ 5000-1 - Northern Electric Co. Ltd.;

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 10 x 6 x 6 inch / 254 x 152 x 152 mm

• Notes
• Reverse dial (kHz numbers in reverse sequence, i.e. 150 at left and 55 at right side) and an extra tuning condenser on top of the main tuner. Painted bakelite.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Price in first year of sale
• 28.00 CND

• Circuit diagram reference
• Radio College of Canada

• Mentioned in
• - - Manufacturers Literature

• Literature/Schematics (1)
• Northern Electric Pages 90, 91, 102

• Author
• Model page created by John Allen. See "Data change" for further contributors.
