413OC

413OC; Paillard AG; St. (ID = 15404) Radio
413OC; Paillard AG; St. (ID = 699546) Radio 413OC; Paillard AG; St. (ID = 699551) Radio
413OC; Paillard AG; St. (ID = 699549) Radio 413OC; Paillard AG; St. (ID = 699552) Radio
413OC; Paillard AG; St. (ID = 699555) Radio 413OC; Paillard AG; St. (ID = 699556) Radio
Use red slider bar for more.
413OC; Paillard AG; St. (ID = 699546) Radio
Paillard AG; St.: 413OC [Radio] ID = 699546 900x577
Select picture or schematic to display from thumbnails on the right and click for download.
For model 413OC, Paillard AG; St. Croix

Country:  Switzerland
Manufacturer / Brand:  Paillard AG; St. Croix
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH3 6K7GT 6Q7GT 6F6G 80
Main principle Super-Heterodyne (Super in general); ZF/IF 470 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220; 250 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out
from Radiomuseum.org Model: 413OC - Paillard AG; St. Croix
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.


All listed radios etc. from Paillard AG; St. Croix
Here you find 539 models, 250 with images and 284 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.






Forum contributions about this model
Paillard AG; St.: 413OC
Threads: 1 | Posts: 5
Hits: 3201     Replies: 4
paillard: Will a Paillard be?
Júlio Branco
24.Nov.09
  1



 Hi all radiophiles,

They offered me this radio, I judge to be a Paillard the schematic that is here coincides with the circuit of the radio, it has the same valves, and the onlooker is that he has a label in paper glued in the chassis, with they can verify in the pictures that I present. The cabinet is totally made in sheet iron.

In the dial glass he can see that it has in blue “Blue Star.” Will the name of the model be and is the number 413 model number? Or will the manufacturer be “BLUE STAR?”

See the pictures:

Thank you for your collaboration,

Regards

Júlio Branco



Ernst Erb
25.Nov.09
  2

When you look at the picture gallery for Paillard, you will see some similar models like this model 413. I see there that Paillard started this type of cabinet in 1936 with the model 20 and 25. Later it was the model 39 with already the same scale and type of chassis in respect of the knobs. In 1938 there is also an export version "Export" 38 - but with an other chassis (see the knobs) in the very similar cabinet.

Also the model 29 from 1939 has a metal cabinet but quite a different concept for a most cheap radio in high quality. The scale is sitting on the shaft of the tuning condenser, rotating with it. This disk is operated by hand at the right side of the set - no knob for station finding. The follower of this was Volksradio 411.

Also in 1939 came the Paillard 402 (broadcast and long waves onnly) with the same cabinet and chasssis type but 6J8G, 6D6, 75, EL3 and 80 of this model in question here - as also model 403M (M stands for metal case) with thre wave bands (incl. SW). The same radio could be bought in wood.

In 1940/41 the model 415 and 415A in a similar metal housing have an other chassis (see knobs).

The 413OC fits into 1940/41, using other tubes (of what was available at that time) than Paillard 402. Without doubt you can load your pictures to the Paillard 413OC. We will have to wait until somebody will know more about "BlueStar". More would be pure speculation - like: It could be for the French speaking market and OC could mean short wave (ondes courtes). Blue Star could be a label of a reseller.

By uploading the pictures you can write in the picture legend that we bring further notice about BlueStar in this thread. Thank you for uploading the pictures. One model less without pictures ...

Júlio Branco
26.Nov.09
  3

Hi friend Radiophile Esnst,

Thank you for your quick clarification on the radio Paillard. I was with my knowledge on this richer matter.

When making the repair of radio I came across the original components of it is own manufacture Paillard, eg electrolytic capacitor that I present here in this forum.





No doubting of your explanations, there is no doubt that actually it is a radio whose manufacturer is Paillard and the proof, as they say; it is proved that these and other unique components that radio still have.

Soon I will upload the photos in Rmorg.

Again, thank you for your attention on this issue.



Best Regards

Júlio Branco

Georg Richter
30.Nov.09
  4

Allow me to object:

The shown capacitor is not made by "Paillard", but by "CONDENSATEURS FRIBOURG S.A."  in the town Fribourg, Switzerland.

History:

http://www.montena.com/montena/en/index.php?l=historique

Regards,

GR

Júlio Branco
18.Dec.09
  5

Hello Georg,

Thank you very much for your explanation

Cordially

 Júlio Branco




Paillard AG; St.: 413OC
End of forum contributions about this model
