Model: 5 Transitone



Old radios, englishAlte Radios, deutschRadios antiguas, españolMusée de radio, francaisRadio antiche, italiano
Antique radios, Old Time Radios

Please click your language flag. Bitte Sprachflagge klicken.

5 Transitone


Country: United States of America (USA) Manufacturer/Brand: Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1934 Type: Car RadioAutoradio - ist nicht immer als solches bezeichnet, da erst später mit Code unterschieden. Mod.-ID = 50954 previous | Result List | next | New search for Radios etc. Schematics etc.: 3 (for members) Principle Super-Heterodyne (Super in general); IF-Freq. 460 kHz; 2 AF-stage(s)Superhet - normally without a preamplification stage (as far as known). Please use «To add informations to model» if you know more! Thanks.
Récepteur TSF superhétérodyne. Normalement sans préamplification de HF.
Superhet ohne Vorstufe.
Nicht immer war bei der Erfassung klar, ob der Empfänger eine Vorstufe aufweist oder nicht. Im Zweifelsfall kam das Gerät in diese Kategorie.

Wave bands Broadcast only (MW).Mittelwellenempfänger
Power type and voltage Storage Battery for all
Loudspeaker/pwr.out Electro Magnetic Dynamic LS (moving-coil with field excitation coil)Electro magnetic dynamic loudspeaker (moving-coil principle by Rice-Kellog) with field excitation coil - mostly used as choke.
Haut parleur dynamique avec bobine d`excitation - plus souvent aussi utilisé pour le self.
Elektrodynamischer Lautsprecher mit Erregerspule für das Magnetfeld (Fremderregung), meist gleichzeitig als Siebglied dienend.

www.radiomuseum.org Model: 5 Transitone Valves / Tubes 5: 6A7     (more for members)
Notes The model uses a vibrator for +B.
External source of data Ernst Erb
Circuit diagram reference Rider's Perpetual, Volume 3Ave, RD 2, Canandaigua, NY 14424-9564, USA.
