Model: P-1617 (P1617) Packard

Antique radios, Old Time Radios

P-1617 (P1617) Packard

Country: United States of America (USA) Manufacturer/Brand: Philco, Philadelphia Stg. Batt. Co.; USA
Year: 1938 Type: Autoradio - ist nicht immer als solches bezeichnet, da erst später mit Code unterschieden.Car Radio Mod.-ID = 51460 previous | Result List | next | New search for Radios etc. Schematics etc.: 0 (for members) Principle Superhet with a preamplification stage.
Please use «To add informations to model» if you know more! Thanks.
Récepteur TSF superhétérodyne avec préamplification de HF.
Superhet mit HF-Vorstufe.
Superhet with RF-stage; IF-Freq. 470 kHz; 2 AF-stage(s)
Wave bands MittelwellenempfängerBroadcast only (MW).
Power type and voltage Storage Battery for all
Loudspeaker/pwr.out Electro magnetic dynamic loudspeaker (moving-coil principle by Rice-Kellog) with field excitation coil - mostly used as choke.
Haut parleur dynamique avec bobine d`excitation - plus souvent aussi utilisé pour le self.
Elektrodynamischer Lautsprecher mit Erregerspule für das Magnetfeld (Fremderregung), meist gleichzeitig als Siebglied dienend.Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
from Radiomuseum.org Model: P-1617 (P1617) Packard Valves / Tubes 6: 7A7 (more for members)
Notes This model is equipped with a vibrator for the generation of B+.

Philco_P-1617_Ebay_seller_k.weaverfamily

Philco_P-1617_Ebay_seller_k.weaverfamily. Dial view

Philco_P-1617_Ebay_seller_k.weaverfamily. Chassis view

More pictures

No further information on

P-1617 (P1617) Packard (Philco, Philadelphia Stg. Batt. Co.; USA)
