Studebaker-Philco Transitone Superheterodyne AC260 ST-3 (Ch= T3)

Philco, Philadelphia Stg. Batt. Co.; USA

  • Year
  • 1937 ??
perfect model
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 51567

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 6
  • Main principle
  • Superhet with RF-stage; ZF/IF 260 kHz
  • Power type and voltage
  • Storage and/or dry batteries / Positive ground!: 6 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • from Radiomuseum.org
  • Model: Studebaker-Philco Transitone Superheterodyne AC260 ST-3 - Philco, Philadelphia Stg. Batt
  • Dimensions (WHD)
  • 7 x 7.5 x 11 inch / 178 x 191 x 279 mm
  • External source of data
  • Ernst Erb
  • Circuit diagram reference
  • Rider's Perpetual, Volume 8 = 1937 and before

 Collections | Museums | Literature

Collections

The model Studebaker-Philco Transitone Superheterodyne AC260 is part of the collections of the following members.
