202 electronic 22GC002 /05T Mit Tachoregelung

Philips Radios - Deutschland

  • Year
  • 1971 ?
  • Category
  • Sound/Video Recorder and/or Player
  • Radiomuseum.org ID
  • 171594
    • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 8
  • Wave bands
  • - without
  • Details
  • Record Player (not changer)
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 240 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: 202 electronic 22GC002 /05T [Mit Tachoregelung] - Philips Radios - Deutschland
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 390 x 120 x 330 mm / 15.4 x 4.7 x 13 inch
  • Notes
  • Plattenspieler Electronic 22GC002 mit Tachoregelung.
    33 1/3; 45; 78 U/min.
    Zubehör: Vorverstärker 22GH905.



    Philips Servicenote: Ref. Afsp 174, 22GC002, March 1971

    Change electrical settings

    See item 2 of the electrical measurements in the documentation.

    Corrected adjustment of the rotation speed: set R19, R22 and R27 in the center position and adjust R20, R23 and R28 for the proper speed.

  • Net weight (2.2 lb = 1 kg)
  • 4.8 kg / 10 lb 9.2 oz (10.573 lb)
  • Source of data
  • -- Original-techn. papers.
  • Author
  • Model page created by a member from D. See "Data change" for further contributors.

 Collections | Museums | Literature

 Forum

Forum contributions about this model: Philips Radios -: 202 electronic 22GC002 /05T

Threads: 1 | Posts: 1

I just uploaded the original Philips Service anounsment ,march 1971,for the remark how to

correctly adjust the Tacho.

Its in Dutch.

However its for the completness of the documentation and the remark in the discription of

this chassis is indeed the correct procedure.

" Corrected adjustment of the rotation speed: set R19, R22 and R27 in the center position and adjust R20, R23 and R28 for the proper speed. "

Regards

Maurice.

Maurice Hamm, 07.Nov.23
