• Year
  • 1966–1968
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 107413

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 10
  • Main principle
  • Superhet with RF-stage; ZF/IF 10700 kHz
  • Tuned circuits
  • 11 FM circuit(s)
  • Wave bands
  • FM Broadcast Band Only
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 127; 220; 245 Volt
  • Loudspeaker
  • - For headphones or amp.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 22GH927 /00 - Philips; Eindhoven tubes
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 355 x 89 x 155 mm / 14 x 3.5 x 6.1 inch
  • Notes
    • Stereo tuner 87.5 - 108 MHz.
    • Contains diodes: 9 x AA119, 2 x BA100, 1 x BA102, 1 x BZY59, 1 x BZY61.
  • Net weight (2.2 lb = 1 kg)
  • 1.7 kg / 3 lb 11.9 oz (3.744 lb)
  • Price in first year of sale
  • 329.00 Hfl.
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Peter Spies. See "Data change" for further contributors.
