253V (253 V) var. 2

ID = 96926

Country: Netherlands	Manufacturer/Brand: Philips; - Eindhoven; Netherlands
Year: 1947	Type: Car Radio
Valves / Tubes	4: EK2 EF9 EBC3 EL2

Principle	Super-Heterodyne (Super in general); IF-Freq. 468 kHz
Tuned circuits	5 AM circuit(s);
Wave bands	Broadcast (MW) and Long Wave.
Power type and voltage	Batteries (storage and/or dry) / 6 Volt
Loudspeaker/pwr.out	Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
from Radiomuseum.org	Model: 253V [var. 2]
Material	Metal case
Dimensions (WHD)	185 x 245 x 190 mm / 7.3 x 9.6 x 7.5 inch
Notes	Vibrator 7946.

This model was suggested by John Koster.
