Anodenspannungsapparat 372 neu

Philips Radios - Deutschland

  • Year
  • 1927–1930 ?
perfect model
  • Category
  • Power supply/conditioner or battery or charger
  • Radiomuseum.org ID
  • 7437
    • Brand: Deutsche Philips-Ges.

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Valves / Tubes
  • 373
  • Wave bands
  • - without
  • Details
  • Power: B-Battery Eliminator
  • Power type and voltage
  • Alternating Current supply (AC)
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • TUBES VISIBLE, material not known.
  • from Radiomuseum.org
  • Model: Anodenspannungsapparat 372 [neu] - Philips Radios - Deutschland
  • Shape
  • Tablemodel, with any shape - general.
  • Dimensions (WHD)
  • 120 x 260 x 198 mm / 4.7 x 10.2 x 7.8 inch
  • Notes
  • Netzanode für 2 regelbare Anodenspannungen. [1-74] Siehe immer bei Fabrikation Holland. Hier nur aufgeführt, weil oft bei deutschen Sammlern anzutreffen.

    Die Höhenangabe ist inklusiv Röhre. Ohne Röhre sind es 168 mm.

    We have only given prove for 1928. Therefore the question mark behind 1927-30.

  • Net weight (2.2 lb = 1 kg)
  • 4.5 kg / 9 lb 14.6 oz (9.912 lb)
  • Price in first year of sale
  • 93.00 RM
  • Picture reference
  • Eine Abbildung findet sich im Doppelband "Radios von gestern"

 Collections | Museums | Literature

Collections

The model Anodenspannungsapparat is part of the collections of the following members.

Museums

The model Anodenspannungsapparat can be seen in the following museums.

 Forum

Forum contributions about this model: Philips Radios -: Anodenspannungsapparat 372

Threads: 1 | Posts: 4

Bei meinem Philips Anodenspannungsapparat Type 372, aus den Jahren 1927 – 1930, ist in das Typenschild eine Versorgungsspannung von 143 Volt Wechselspannung 50 Hz eingeschlagen.

Kann mir jemand sagen, wo dieses Gerät damals eingesetzt wurde?

Wie viel verschiedene Versorgungsspannungen gab es und welche?

Dieter ADAM, 27.Dec.18

Weitere Posts (4) zu diesem Thema.
