260 ; Peirce Wire Recorder (ID = 987742) R-Player
Peirce Wire Recorder: 260 [R-Player] ID = 987742 933x701
Select picture or schematic to display from thumbnails on the right and click for download.
For model 260, Peirce Wire Recorder, Evanston, IL

Country:  United States of America (USA)
Manufacturer / Brand:  Peirce Wire Recorder, Evanston, IL
Year: 1948 ? Category: Sound/Video Recorder and/or Player
Valves / Tubes 4: 6J7 6SQ7 6K6 6X5
Main principle Audio-Amplification
Wave bands - without
Details Wire Recorder (or -Player)
Power type and voltage Alternating Current supply (AC) / 110-120 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 10 cm = 3.9 inch
Power out
from Radiomuseum.org Model: 260 - Peirce Wire Recorder, Evanston
Material Metal case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 310 x 260 x 230 mm / 12.2 x 10.2 x 9.1 inch
Net weight (2.2 lb = 1 kg) 9.110 kg / 20 lb 1.1 oz (20.066 lb)
Price in first year of sale 90.00 $

Model page created by Jose Mayoral-Diaz. See "Data change" for further contributors.
