| Country: Italy | Manufacturer/Brand: Prandoni |
| Year: 1978 ?? | Type: Radio or Tuner |
| Transistors | There are transistors, but the number is unknown: |
|---|---|
| schematic requested | |
| Principle | Super-Heterodyne (Super in general); IF-Freq. 467 kHz |
|---|---|
| Wave bands | Broadcast only (MW). |
| Power type and voltage | Line / Batteries (any type) / 220 / 5x1,5 Volt |
| Loudspeaker/pwr.out | Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / 0.7 W / Ø 10 cm = 3.9 inch |
| from Radiomuseum.org | Model: 85 |
| Material | Modern plastics (no Bakelite or Catalin) |
| Shape | Portable, e.g. Portable Radio (with or without mains > 8 inch). |
| Dimensions (WHD) | 240 x 130 x 60 mm / 9.4 x 5.1 x 2.4 inch |
This model was suggested by Fabio Masetti.
