Realistic DX-398

Realistic DX-398; Radio Shack Tandy, (ID = 1474570) Radio Realistic DX-398; Radio Shack Tandy, (ID = 265021) Radio
Realistic DX-398; Radio Shack Tandy, (ID = 1474571) Radio Realistic DX-398; Radio Shack Tandy, (ID = 1474572) Radio
Realistic DX-398; Radio Shack Tandy, (ID = 1474750) Radio Realistic DX-398; Radio Shack Tandy, (ID = 1493835) Radio
Realistic DX-398; Radio Shack Tandy, (ID = 1493836) Radio
Use red slider bar for more.
Realistic DX-398; Radio Shack Tandy, (ID = 1474570) Radio
Radio Shack Tandy,: Realistic DX-398 [Radio] ID = 1474570 930x934
Select picture or schematic to display from thumbnails on the right and click for download.
For model Realistic DX-398, Radio Shack (Tandy, Realistic); USA

Country:  United States of America (USA)
Manufacturer / Brand:  Radio Shack (Tandy, Realistic); USA
Year: 1996 Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Principle Superhet, double/triple conversion
Wave bands Broadcast, Long Wave, more than 2 x SW plus FM.
Details
Power type and voltage Dry Batteries / 4 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7 cm = 2.8 inch
Power out
from Radiomuseum.org Model: Realistic DX-398 - Radio Shack Tandy, Realistic;
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (usable without mains)
Dimensions (WHD) 215 x 133 x 38 mm / 8.5 x 5.2 x 1.5 inch
Notes

AM coverage 153 - 29999 kHz; AM, SSB (BFO), two IF bandwidths (6.5/4 kHz), direct frequency keypad entry, 306 partly pre-programmed alphanumeric memories, clock / timer, RDS on FM, also sold as Sangean ATS-909 .

Originally supplied with protective soft case.

Net weight (2.2 lb = 1 kg) 0.8 kg / 1 lb 12.2 oz (1.762 lb)
Price in first year of sale 200.00 USD
Collectors' prices

Model page created by Martin Bösch. See "Data change" for further contributors.
