Radiobell RB420

Radiobell RB420; Bell Telephone (ID = 97178) Radio Radiobell RB420; Bell Telephone (ID = 97179) Radio
Radiobell RB420; Bell Telephone (ID = 1132936) Radio Radiobell RB420; Bell Telephone (ID = 1132937) Radio
Radiobell RB420; Bell Telephone (ID = 1132938) Radio Radiobell RB420; Bell Telephone (ID = 1132939) Radio
Radiobell RB420; Bell Telephone (ID = 1132942) Radio Radiobell RB420; Bell Telephone (ID = 1785107) Radio
Use red slider bar for more.
Radiobell RB420; Bell Telephone (ID = 97178) Radio
Bell Telephone: Radiobell RB420 [Radio] ID = 97178 800x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model Radiobell RB420, Bell Telephone Manufacturing (Radiobell, Standard); Antwerp

Country:  Belgium
Manufacturer / Brand:  Bell Telephone Manufacturing (Radiobell, Standard); Antwerp
Brand

Radiobell
Year: 1953/1954 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH41 EF41 EAF41 EL84 EM34 AZ41
schematic requested
Main principle Super-Heterodyne (Super in general)
Wave bands Ready for FM, has Broadcast, Long Wave, Short wave.
Details
Power type and voltage Alternating Current supply (AC) / 115; 125; 135; 150; 220; 250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 21 cm = 8.3 inch
Power out
from Radiomuseum.org Model: Radiobell RB420 - Bell Telephone Manufacturing
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 600 x 360 x 290 mm / 23.6 x 14.2 x 11.4 inch
Notes Prepared for FM (FM dial glass present), needs decoder retrofitted.
Collectors' prices

Model page created by Albert Aerts †. See "Data change" for further contributors.
