Direction Finder Ray-DF

Direction Finder Ray-DF; Raytheon Mfg. Co.; (ID = 659430) Radio Direction Finder Ray-DF; Raytheon Mfg. Co.; (ID = 659428) Radio
Direction Finder Ray-DF; Raytheon Mfg. Co.; (ID = 624955) Radio
Use red slider bar for more.
Direction Finder Ray-DF; Raytheon Mfg. Co.; (ID = 659430) Radio
Raytheon Mfg. Co.;: Direction Finder Ray-DF [Radio] ID = 659430 473x492
Select picture or schematic to display from thumbnails on the right and click for download.
For model Direction Finder Ray-DF, Raytheon Mfg. Co.; Cambridge, USA (also tubes):
Ebay auction 220425095727 / adopted pic.

Country:  United States of America (USA)
Manufacturer / Brand:  Raytheon Mfg. Co.; Cambridge, USA (also tubes)
Year: 1970 ?? Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Principle Super-Heterodyne (Super in general)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage Dry Batteries / 8 x 1,5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Direction Finder Ray-DF - Raytheon Mfg. Co.; Cambridge,
Material Modern plastics (no Bakelite or Catalin)
Shape Portable set > 8 inch (usable without mains)
Notes Raytheon Radio Ray-DF Direction Finder, FM/AM 5 Band;
Coverage:
LF/LW: 180 ... 400 KHz,
BC/AM/MW: 540 ... 1600 KHz,
MF/MB: 1.6 ... 4.0 MHz,
FM: 86 ... 109 MHz,
VHF: 146 ... 176 MHz,
Featuring:
Dial lamp, DF level control, BFO, DF level meter, separate AM & FM/VHF band selector, telescopic & swivel ferrite rod for navigation on top with compass rose, earphones jack, carrying strap, swivel stand, made in Japan.
