For model 67QR73FM-M, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1956 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECC85 ECH81 EF89 EABC80 EM34 EL84
schematic requested
Principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and FM.
Details
Power type and voltage Alternating Current supply (AC) / 110-240 Volt
Loudspeaker 4 Loudspeakers
Power out
from Radiomuseum.org Model: 67QR73FM-M - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 23 x 13.5 x 9 inch / 584 x 343 x 229 mm
Notes Possibly made by Graetz for RCA as a model for US soldiers in Europe, hence LW and 240 V.
Collectors' prices
Source of data -- Collector info (Sammler)

Model page created by Gottfried Silberhorn. See "Data change" for further contributors.
