810K ; RCA RCA Victor Co. (ID = 190324) Radio
RCA RCA Victor Co.: 810K [Radio] ID = 190324 391x600
Select picture or schematic to display from thumbnails on the right and click for download.
For model 810K, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1937 Type: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6K7 6J7 6L7 6K7 6G5 6H6 6N7 6F6 6F6 5T4
Principle Superhet with RF-stage; ZF/IF 460 kHz
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 105-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out 10 W (unknown quality)
from Radiomuseum.org Model: 810K - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with Push Buttons.
Dimensions (WHD) 26 x 42 x 12 inch / 660 x 1067 x 305 mm
Collectors' prices
External source of data Ernst Erb
Source of data The Radio CollectorGrinder, 1995
Circuit diagram reference Rider's Perpetual, Volume 9 = 1938 and before
Mentioned in Pre-War Consoles; Stein, 2000
Literature/Schematics (1) RCA Victor Service Notes for 1937 (RCA Redbook)
