• Country
• United States of America (USA)

• Manufacturer / Brand
• RCA (RCA Victor Co. Inc.); New York (NY)

• Year
• 1972 ?

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 178303

• • alternative name: RCA Manufacturing || Victor Talking Machine

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• Semiconductors present.

• Semiconductors

• Wave bands
• Wave Bands given in the notes.

• Power type and voltage
• Alternating Current supply (AC) / 60Hz, 120 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: Master Chro-Bar Generator/Signalyst WR-515A - RCA RCA Victor Co. Inc.; New

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 10 x 4 x 8 inch / 254 x 102 x 203 mm

• Notes

• The RCA Master Chro-Bar Generator/Signalyst WR-515A is a NTSC test generator with the following outputs.

  RF Output
  Frequency...........Picture carrier 61.25 MHz
  Impedance..........75 ohms or 300 ohms
  Level..................Adjustable up to 50 mV (across 300 ohms)

  IF Output
  Frequency...........45.75 MHz
  Impedance..........75 ohms
  Level..................Adjustable up to 50 mV

  Video Output
  Frequency...........4-5 MHz
  Impedance..........75 ohms
  Level..................Adjustable up to 2 V (across 75 ohms)





• Net weight (2.2 lb = 1 kg)
• 6 lb (6 lb 0 oz) / 2.724 kg
