SHF-5 "Mark IV" Ch= RS-151B

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880296) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880297) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880298) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880299) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880300) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880301) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880302) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880303) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880304) R-Player

SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1880305) R-Player
SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879899) R-Player SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879900) R-Player
SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879901) R-Player SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879902) R-Player
SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879903) R-Player SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879904) R-Player
Use red slider bar for more.
SHF-5 'Mark IV' Ch= RS-151B; RCA RCA Victor Co. (ID = 1879899) R-Player
RCA RCA Victor Co.: SHF-5 "Mark IV" Ch= RS-151B [R-Player] ID = 1879899 1000x864
Select picture or schematic to display from thumbnails on the right and click for download.
For model SHF-5 "Mark IV" Ch= RS-151B, RCA (RCA Victor Co. Inc.); New York (NY)

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1957/1958 Category: Sound/Video Recorder and/or Player
Valves / Tubes 5: 6CG7 6CG7 6V6GT 6V6GT 5Y3GT
schematic requested
Main principle Audio-Amplification
Wave bands - without
Details Changer (Record changer); Hi-Fi equipment
Power type and voltage Alternating Current supply (AC) / 60 Hz, 115 Volt
Loudspeaker 4 Loudspeakers
Power out 10 W (15 W max.)
from Radiomuseum.org Model: SHF-5 "Mark IV" Ch= RS-151B - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Console with any shape - in general
Dimensions (WHD) 28.5 x 32 x 18 inch / 724 x 813 x 457 mm
Notes

The RCA SHF-5 is an AC operated 5 tube mono record player with automatic 4 speed record changer.  Has Qty(2) PM 3.5" tweeters and Qty(2) PM 12" woofers. Uses record changer RP-205C-2 which operates at 16 2/3, 33 1/2, 45 or 78 rpm speeds.  Record capacity is up to fifteen 7 inch, twelve 10 inch, ten 12 inch or ten intermixed 10 inch and 12 inch records.

Cabinet was available in Mahogany, Maple or Oak.

The RCA 9-T-1 AM-FM tuner (using 8 tube chassis RC-1155A) was available as an accessory for the SHF-5.

The RCA SHF-4 was similar to the SHF-5 but had a factory installed 9-T-1 tuner.

Net weight (2.2 lb = 1 kg) 66 lb (66 lb 0 oz) / 29.964 kg
Mentioned in - - Manufacturers Literature (RCA Victor Service Data Datasheet - File 1957 No. 16)
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Set 387, folder 13 dated 2-58)

Model page created by Larry Long. See "Data change" for further contributors.
