• Country
• Canada

• Manufacturer / Brand
• RCA Victor (International), Montreal

• Year
• 1941/1942

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 148229

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 6SK7 6SA7 6SK7 6SQ7 6U5 6F6G 5Y4G

• Main principle
• Superheterodyne (common); ZF/IF 455 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 105-125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm

• Material
• Wooden case

• from Radiomuseum.org
• Model: A38 - RCA Victor International,

• Shape
• Console: Chairside Radio.

• Dimensions (WHD)
• 28.75 x 39.25 x 13.5 inch / 730 x 997 x 343 mm

• Notes
• RCA Victor A25 and A38 share the same schematics with CGE KL-70 and KL-76.

• Price in first year of sale
• 149.00 CAD

• Source of data
• -- Original prospect or advert

• Circuit diagram reference
• Radio College of Canada

• Mentioned in
• CGE Sheet 74

• Literature/Schematics (1)
• Pre-War Consoles

• Author
• Model page created by Ashis Mukerjea. See "Data change" for further contributors.
