• Year
  • 1927/1928
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 115572

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 8
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Storage and/or dry batteries
  • Loudspeaker
  • Magnetic loudspeaker (reed) generic.
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: Ideal 8 - Rees Radio; Paris
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 445 x 430 x 205 mm / 17.5 x 16.9 x 8.1 inch
  • Notes
  • The model Ideal 8 has a big internal coil antenna which has to be oriented for good reception. Jean Claude Terrat has given the following tubes: SG210 HL210 HL210 HL210 HL210 L210 220P 220P. We believe that in fact it should have: HF amp = Cossor 215SG; Oscillator = Cossor 210HL; Mixer/1st Det = Cossor 210HL; 1st IF = Cossor 210HL; 2nd IF = Cossor 210LF; 2nd Det = Cossor 210LF; 1ST LF = Mullard PM1LF and LF Final = Gecovalve P215.
  • Net weight (2.2 lb = 1 kg)
  • 6 kg / 13 lb 3.5 oz (13.216 lb)
  • External source of data
  • Nico van Dijk
  • Author
  • Model page created by Jean Claude Terrat. See "Data change" for further contributors.
