331GL-H Holzgehäuse

SABA; Villingen

  • Year
  • 1934/1935
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 6664
    • Brand: Schwer & Söhne, GmbH

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 3
  • Main principle
  • TRF without regeneration; 1 Special; 1 AF stage(s); Super, reaction, but not adjustable
  • Tuned circuits
  • 1 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Direct Current supply (DC) / 110; 160; 220; 240 Volt
  • Loudspeaker
  • Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 331GL-H [Holzgehäuse] - SABA; Villingen
  • Shape
  • Tablemodel, high profile (upright - NOT Cathedral nor decorative).
  • Dimensions (WHD)
  • 410 x 450 x 300 mm / 16.1 x 17.7 x 11.8 inch
  • Price in first year of sale
  • 253.00 RM
  • Mentioned in
  • -- Schematic (OTO-Schaltungen)
  • Literature/Schematics (1)
  • -- Original-techn. papers.

 Collections | Museums | Literature

Collections

The model is part of the collections of the following members.

 Forum

Forum contributions about this model: SABA; Villingen: 331GL-H

Threads: 1 | Posts: 1

Für die original Saba Serviceunterlagen zum Gerät siehe auch
Saba Kundendienstschrift Nr. 4

Gruß

Dirk Becker

Dirk Becker, 11.Jan.05

Weitere Posts (1) zu diesem Thema.
