For model HiFi Stereo System C3000, SABA; Villingen:
Sammlung

Country:  Germany
Manufacturer / Brand:  SABA; Villingen
Brand

Schwer & Söhne, GmbH
Year: 1985 ?? Type: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) Semiconductors present.
Principle Super-Heterodyne (Super in general)
Wave bands Broadcast, Long Wave and FM.
Details Other Combination - see Notes
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: HiFi Stereo System C3000 - SABA; Villingen
Material Modern plastics (no Bakelite or Catalin)
Shape Book-shelf unit.
Dimensions (WHD) 420 x 340 x 380 mm / 16.5 x 13.4 x 15 inch
Notes HiFi Stereo System C3000, bestehend aus Plattenspieler P3000, Tuner T3000, Verstärker V3000 und Kassettenrecorder D3000,
Tuner:
UKW 88 bis 108 MHz mit 7 einstellbaren Speichern, Pilottaste mit LED, Stereo >Mitte< Anzeige, 75 Ohm Antenneneingang,
Plattenspieler: Pitchregelung, 33 und 45 Upm, Lift-Tonarm,
Verstärker: Bässe/Höhen und Balance-Einstellung,
Kassette: Vollautomatic Stop-System, mech. Zählwerk, Dolby-NR System, Pegel links und rechts Anzeige über LED, Bandsorte Standard/CrO2/Metal,Kopfhörer-Buchse, Buchse Mikrofon L/R, 5 Pol. DIN-Buchse Aufn./Wiedergabe.
Net weight (2.2 lb = 1 kg) 12.8 kg / 28 lb 3.1 oz (28.194 lb)
Collectors' prices
Source of data - - Data from my own collection

Model page created by Karlheinz Fischer. See "Data change" for further contributors.

All listed radios etc. from SABA; Villingen
Here you find 1400 models, 1231 with images and 873 with schematics.




Forum contributions about this model
SABA; Villingen: HiFi Stereo System C3000
Threads: 1 | Posts: 1
Hits: 719     Replies: 0
saba: C3000; HiFi Stereo System
Karlheinz Fischer
22.Sep.08
  1

Erweiterte Info zu Pilottaste:

Diese Taste haben einige Receiver/Tuner von SABA. Sie wird benötigt, wenn man Stationstasten hat. Drückt man eine Stationstaste und dann die Pilottaste, so zeigen Instrumente oder LEDs die Richtung an, die der große Skalenzeiger gehen müßte, um den Sender zu erreichen, der auf der Stationstaste liegt.
